Displacement: 195~490 cc/rev
Max.differential pressure: 167~206 bar
Higher mechanical and volumetric efficiency.
Better lowest steady speed with high pressure
Cost competitive due to simple structure design.
Patented automatic 2-speeds is available.
Wheel-side output, compact machine structure.
| Displacement (cm3/rev.) | Fixed | 195 | 310 | 350 | 390 | 440 | 490 |
| Variable | 97.5 | 155 | 175 | 195 | 220 | 245 | |
| Max.output torque(Theoretically) (N·m) | 518 | 1020 | 1148 | 1279 | 1443 | 1607 | |
| Max. differential pressure (bar) | 167 | 206 | 206 | 206 | 206 | 200 | |
| Max.flow (L/min) | 20 | 20 | 20 | 20 | 20 | 20 | |
| Max.case pressure (bar) | 5 | 5 | 5 | 5 | 5 | 5 | |
Automatic two-speed pilot pressure (bar) | 34 | 34 | 34 | 34 | 34 | 34 | |
| Weight(kg) | 21.0 | 23.0 | 23.5 | 24.0 | 24.5 | 25.0 | |
